Product Description
➩ Product Advantage
1. Superior Temperature Control & Insulation
The LNG semi-trailer is engineered to maintain the gas at a constant temperature of approximately -160°C, preserving its liquid state and preventing evaporation. High-quality insulation materials combined with a fully enclosed system minimize heat transfer, ensuring the LNG remains stable and secure during transport.
2. High-Strength Alloy Steel Tank
The semi-trailer’s tank is constructed from high-strength alloy steel, designed to withstand both internal and external pressure changes. This robust design ensures the LNG is safely contained, withstanding the rigors of transportation and meeting international safety standards to prevent pressure fluctuations that could pose a risk.
3. Advanced Sealing System for Leak Prevention
Equipped with an efficient sealing system, the LNG semi-trailer maintains the gas in a closed state at all times, utilizing high-performance valves and pressure regulators. This reduces the risk of leakage while automatically adjusting temperature and pressure, ensuring a smooth and safe journey for the liquefied natural gas.
4. Comprehensive Safety Features
Safety is paramount in the design of our LNG semi-trailer. It is equipped with explosion-proof features, an automatic fire extinguishing system, and a gas leak detection system, guaranteeing that the vehicle remains safe even in extreme conditions. Compliance with international safety regulations ensures both personnel and equipment are protected throughout the transport process.
5. Eco-Friendly Transport
LNG is a cleaner energy alternative compared to traditional fuels, offering lower carbon emissions and higher energy efficiency. Our LNG semi-trailer is designed to maximize the benefits of LNG by minimizing gas waste and improving energy use, making it a sustainable choice for the future of transportation.
6. Customizable Configurations
To meet the diverse needs of our customers, we offer flexible customization options. Depending on transportation volume, distance, and environmental conditions, customers can select the ideal tank size, temperature control system, and other specifications to optimize transportation efficiency.
➩ Technical Parameters
| ltem | specifications | Remark |
| Material | Carbon steel/stainless steel/Aluminum | |
| Axles | 2/3/4*13ton capacity | OCT,FUWA,BPWor other Brand |
| Suspension | Mechanical suspension | Air /bogie suspension optiona |
| Leaf spring | 10pcs | Air bag lifting optional |
| Tire | 12R22.5,11R22.5,315/80R22.5, 385/65R22.5 | Size andbrand optiona |
| Rim | 9.00-22.5,8.25-22.5,11.75-22.5 | Other size optiona |
| King pin | 2"/3.5"bolt type,SAE standard | Welding on type optiona |
| Landing gear | 28 Ton two speed | JOST or equivalent brand |
| Tank body | 5mm-7mm | |
| End plate | 6mm-20mm | |
| Man hole | 300mm-500mm | |
| Braking system | Dual linebrake system,Double air chamber ,brake valve,40L air tanks;ABSEBS optional | |
| Electrical | LED light,7ways,24V | |
| Painting | Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting | |
➩ Product Uses
1. Long-distance liquefied natural gas transportation
2. Natural gas storage and distribution
3. LNG filling station distribution
4. Industrial and power plant gas supply
5. Ship and offshore platform energy supply
6. Emergency gas supply
7. Natural gas liquefaction and distribution enterprises
8. Environmental protection projects
