Product Description
➩ Product Advantage
One of the most significant benefits of aluminum alloy is its lightweight nature. Compared to traditional steel trailers, aluminum alloy semi-trailers are 15% to 30% lighter. This reduction in weight not only leads to lower fuel consumption but also increases the vehicle's payload capacity, resulting in more efficient and energy-saving transportation.
Despite being lightweight, aluminum alloy maintains excellent strength and durability. These trailers are designed to withstand intense pressure and impacts while maintaining stability and safety over time. The material's resistance to deformation ensures that aluminum alloy semi-trailers can handle demanding transportation needs without compromising performance.
Aluminum alloy is highly resistant to corrosion, making it ideal for environments prone to rust, such as coastal areas or chemical plants. This quality reduces maintenance costs and extends the trailer's service life. Furthermore, aluminum's resistance to high temperatures makes these trailers suitable for transporting hot materials, ensuring stability in harsh conditions.
Aluminum alloy semi-trailers offer a sustainable advantage as they are fully recyclable, contributing to reduced environmental impact. They also lower operational costs, making them an economically sound choice for businesses. With rising environmental standards, these trailers support the move towards more sustainable transportation practices.
➩ Technical Parameters
| ltem | specifications | Remark |
| Material | Carbon steel/stainless steel/Aluminum | |
| Axles | 2/3/4*13ton capacity | OCT,FUWA,BPWor other Brand |
| Suspension | Mechanical suspension | Air /bogie suspension optiona |
| Leaf spring | 10pcs | Air bag lifting optional |
| Tire | 12R22.5,11R22.5,315/80R22.5, 385/65R22.5 | Size andbrand optiona |
| Rim | 9.00-22.5,8.25-22.5,11.75-22.5 | Other size optiona |
| King pin | 2"/3.5"bolt type,SAE standard | Welding on type optiona |
| Landing gear | 28 Ton two speed | JOST or equivalent brand |
| Tank body | 5mm-7mm | |
| End plate | 6mm-20mm | |
| Man hole | 300mm-500mm | |
| Braking system | Dual linebrake system,Double air chamber ,brake valve,40L air tanks;ABSEBS optional | |
| Electrical | LED light,7ways,24V | |
| Painting | Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting | |
➩ Applications
Aluminum alloy semi-trailers are commonly used in:
Long-Distance Transportation
Cold Chain Logistics
Chemical Transportation
Construction Materials Transport
Food and Beverage Industry
Their lightweight, durable, and eco-friendly features make them an ideal solution for a variety of transport needs.
