➩ Product Advantage
1. Corrosion-Resistant Construction
The tank body is constructed from high-quality corrosion-resistant materials such as stainless steel, fiberglass, or polyethylene-coated alloys. These materials offer excellent protection against corrosive substances like acids, alkalis, and solvents, ensuring the long-term stability of the tank and preventing leaks and damage during transportation.
2. Comprehensive Safety Design
The chemical tank trailer is equipped with multiple safety measures to protect against potential hazards. Features like double sealing, firewalls, pressure relief valves, and gas discharge systems enable rapid response in case of external impacts or internal abnormalities, significantly reducing the risk of explosions or leaks during transport.
3. Anti-Static and Explosion-Proof Features
Given the flammable and explosive nature of many corrosive chemicals, the trailer is designed with anti-static and explosion-proof features. The tank surface is electrostatically sprayed, and the system includes an electrostatic grounding system to prevent the buildup of static electricity, minimizing the risk of fire or explosion during chemical reactions.
4. Temperature Control for Stability
Corrosive liquid tank trailers are built to transport chemicals that require specific temperature conditions. They offer excellent high and low-temperature resistance, making them suitable for transporting temperature-sensitive substances like liquid chlorine and liquid ammonia, while ensuring these chemicals remain stable throughout the journey.
5. Easy to Clean and Maintain
Designed with environmental protection and hygiene in mind, the tank body features a smooth surface with no dead corners, making it easy to clean and ensuring no chemical residues remain. This design is particularly ideal for industries with stringent cleanliness and sanitation requirements, such as food and pharmaceuticals.
6. Customizable to Transportation Needs
These trailers can be tailored to meet various transport specifications, providing flexibility for different chemicals and operational environments. Whether it’s for long-distance deliveries or specialized chemical transportation, corrosive liquid tank trailers offer customizable solutions that meet the unique demands of each client.
➩ Technical Parameters
| ltem | specifications | Remark |
| Material | Carbon steel/stainless steel/Aluminum | |
| Axles | 2/3/4*13ton capacity | OCT,FUWA,BPWor other Brand |
| Suspension | Mechanical suspension | Air /bogie suspension optiona |
| Leaf spring | 10pcs | Air bag lifting optional |
| Tire | 12R22.5,11R22.5,315/80R22.5, 385/65R22.5 | Size andbrand optiona |
| Rim | 9.00-22.5,8.25-22.5,11.75-22.5 | Other size optiona |
| King pin | 2"/3.5"bolt type,SAE standard | Welding on type optiona |
| Landing gear | 28 Ton two speed | JOST or equivalent brand |
| Tank body | 5mm-7mm | |
| End plate | 6mm-20mm | |
| Man hole | 300mm-500mm | |
| Braking system | Dual linebrake system,Double air chamber ,brake valve,40L air tanks;ABSEBS optional | |
| Electrical | LED light,7ways,24V | |
| Painting | Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting | |
➩ Product Uses
Chemical industry
Agriculture and pesticide transportation
Pharmaceutical industry
Emergency chemical transportation
Hazardous goods transportation
