➩ Product Advantage
Durability and Material Strength
These containers are crafted from materials such as high-strength steel, stainless steel, or aluminum alloys, which offer resistance to corrosion, pressure, and impact. The robust tank structure ensures the container can endure the pressures of long-distance transportation and fluctuating external conditions, extending its service life.
Advanced Sealing and Customization
Tank containers feature advanced sealing systems that effectively prevent leakage or evaporation of liquids and gases, ensuring safe transport. Additionally, these containers can be tailored to the specific needs of different goods, such as dangerous chemicals, food products, or pharmaceuticals. Customization options include inner wall coatings, temperature regulation systems, and gas compression devices to meet unique requirements.
Applications
Tank containers are utilized in the chemical, oil, food and beverage, pharmaceutical, and agricultural industries, as well as in the transport of hazardous materials. Their ability to handle a wide range of liquids and gases, while maintaining safety and efficiency, makes them indispensable in modern transportation and logistics systems.
➩ Technical Parameters
| ltem | specifications | Remark |
| Material | Carbon steel/stainless steel/Aluminum | |
| Axles | 2/3/4*13ton capacity | OCT,FUWA,BPWor other Brand |
| Suspension | Mechanical suspension | Air /bogie suspension optiona |
| Leaf spring | 10pcs | Air bag lifting optional |
| Tire | 12R22.5,11R22.5,315/80R22.5, 385/65R22.5 | Size andbrand optiona |
| Rim | 9.00-22.5,8.25-22.5,11.75-22.5 | Other size optiona |
| King pin | 2"/3.5"bolt type,SAE standard | Welding on type optiona |
| Landing gear | 28 Ton two speed | JOST or equivalent brand |
| Tank body | 5mm-7mm | |
| End plate | 6mm-20mm | |
| Man hole | 300mm-500mm | |
| Braking system | Dual linebrake system,Double air chamber ,brake valve,40L air tanks;ABSEBS optional | |
| Electrical | LED light,7ways,24V | |
| Painting | Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting | |
