Product Description
➩ Product Advantage
1. High-Quality Stainless Steel Construction
Made from premium stainless steel materials (such as 304 or 316L), these trailers are built for long-lasting durability. With excellent resistance to corrosion, high temperatures, wear, and oxidation, they are ideal for transporting chemicals, food, and petroleum products in harsh environments, ensuring long-term stability and performance.
2. Strong, Impact-Resistant Design
The structure of the stainless steel tank is designed for high strength, capable of withstanding pressure and impacts during transportation. The tank's thickness and structural design meet international safety standards, effectively preventing accidents like leaks or explosions, even under extreme conditions.
3. High and Low Temperature Resistance
The stainless steel construction allows the tank to maintain stable performance in both high- and low-temperature environments. Whether transporting high-temperature liquids (e.g., hot oil, asphalt) or low-temperature liquids (e.g., liquefied natural gas, liquid nitrogen), these trailers provide reliable temperature control, ensuring materials are transported safely.
4. Efficient Automated Loading and Unloading Systems
Stainless steel tank trailers are typically equipped with automated loading and unloading systems, including pump stations, valves, and liquid level control systems. These systems prevent spills and leaks during loading and unloading, enhancing operational efficiency while saving on labor costs.
5. Easy to Clean and Maintain
The smooth, corrosion-resistant surface of the stainless steel tank makes it easy to clean and maintain. This is especially important in industries like food, beverages, and pharmaceuticals, where cleanliness and hygiene are crucial. The design of the tank ensures that no contaminants affect the quality of transported goods, preserving product integrity.
6. Long-Term Corrosion Resistance
Stainless steel's inherent corrosion-resistant properties protect the tank from damage when transporting a variety of substances, including acidic, alkaline, and saline chemicals. This reduces maintenance needs and extends the trailer's lifespan, making it a cost-effective solution over the long term.
➩ Technical Parameters
| ltem | specifications | Remark |
| Material | Carbon steel/stainless steel/Aluminum | |
| Axles | 2/3/4*13ton capacity | OCT,FUWA,BPWor other Brand |
| Suspension | Mechanical suspension | Air /bogie suspension optiona |
| Leaf spring | 10pcs | Air bag lifting optional |
| Tire | 12R22.5,11R22.5,315/80R22.5, 385/65R22.5 | Size andbrand optiona |
| Rim | 9.00-22.5,8.25-22.5,11.75-22.5 | Other size optiona |
| King pin | 2"/3.5"bolt type,SAE standard | Welding on type optiona |
| Landing gear | 28 Ton two speed | JOST or equivalent brand |
| Tank body | 5mm-7mm | |
| End plate | 6mm-20mm | |
| Man hole | 300mm-500mm | |
| Braking system | Dual linebrake system,Double air chamber ,brake valve,40L air tanks;ABSEBS optional | |
| Electrical | LED light,7ways,24V | |
| Painting | Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting | |
➩ Product Uses
Chemical industry: used to transport various chemical liquids (such as solvents, acid and alkali liquids, fertilizers, etc.), especially for highly corrosive chemicals, the corrosion resistance of stainless steel tanks is very suitable.
Food and beverage industry: used to transport liquid foods (such as milk, juice, cooking oil, etc.) and alcoholic beverages, etc., to ensure the safety and hygiene of food.
Oil and gas industry: used to transport petroleum products (such as gasoline, diesel, lubricants, etc.) and liquefied gases (such as liquefied natural gas, liquefied petroleum gas).
Pharmaceutical industry: used to transport medicinal liquids, injections, etc., to ensure the cleanliness and quality of materials during transportation.
Agriculture: used to transport liquid fertilizers, pesticides, liquid insecticides and other agricultural chemicals.
