Product Description
➩ Product Advantage
Made from high-quality stainless steel, such as 304 or 316L, these trailers offer superior corrosion and oxidation resistance. This makes them ideal for transporting chemicals, food, and petroleum products, even in harsh environments. The material’s high strength ensures long-lasting stability, minimizing the risk of leaks or contamination during transport.
Stainless steel tank trailers excel in extreme temperature environments. Whether transporting hot liquids like asphalt or hot oil, or low-temperature liquids like LNG or liquid nitrogen, these trailers can maintain the necessary conditions. The robust design withstands high pressure and impacts, adhering to international safety standards to prevent accidents.
Equipped with automated loading and unloading systems, such as pumps, valves, and liquid level control, these trailers prevent spills and improve operational efficiency. Additionally, their smooth stainless steel surface ensures easy cleaning, essential for industries like food, beverages, and pharmaceuticals where hygiene is critical.
Stainless steel tank trailers are commonly used in:
Chemical Industry: Transporting corrosive liquids like acids and solvents.
Food & Beverage: Carrying liquid food products and beverages to maintain hygiene.
Oil & Gas: Moving petroleum products and liquefied gases.
Pharmaceuticals: Ensuring safe transport of medicinal liquids.
Agriculture: Delivering liquid fertilizers and pesticides.
These trailers are essential across many sectors, offering both reliability and efficiency in transporting sensitive materials.
➩ Technical Parameters
ltem | specifications | Remark |
Material | Carbon steel/stainless steel/Aluminum | |
Axles | 2/3/4*13ton capacity | OCT,FUWA,BPWor other Brand |
Suspension | Mechanical suspension | Air /bogie suspension optiona |
Leaf spring | 10pcs | Air bag lifting optional |
Tire | 12R22.5,11R22.5,315/80R22.5, 385/65R22.5 | Size andbrand optiona |
Rim | 9.00-22.5,8.25-22.5,11.75-22.5 | Other size optiona |
King pin | 2"/3.5"bolt type,SAE standard | Welding on type optiona |
Landing gear | 28 Ton two speed | JOST or equivalent brand |
Tank body | 5mm-7mm | |
End plate | 6mm-20mm | |
Man hole | 300mm-500mm | |
Braking system | Dual linebrake system,Double air chamber ,brake valve,40L air tanks;ABSEBS optional | |
Electrical | LED light,7ways,24V | |
Painting | Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting |
